Trailer Hitch Classes 1 to 5 and Receiver Sizes, Explained (Canada)

Short answer: a hitch's class (I to V) puts it in a capacity group, and it goes with a receiver size: 1-1/4 in for Classes I and II, 2 in for Classes III and IV, and 2 in, 2-1/2 in or 3 in for Class V. The hitches we list for cars, compact SUVs and EVs are Class I to III; for full-size trucks, Class III to V. The class does not replace the ratings: the ones on the hitch label, the ball mount and in your owner's manual apply, and the lowest one counts.

Hitch classes I to V

Class Receiver Trailer weight, up to
I 1-1/4 in 2,000 lb
II 1-1/4 in 3,500 lb
III 2 in 8,000 lb
IV 2 in 10,000 lb
V 2-1/2 in or 3 in 18,500 lb (2-1/2 in), 21,000 lb (3 in)

Source: Weigh Safe's page on receiver sizes (weigh-safe.com). These are class ceilings: each maker gives its hitch its own rating, often lower. For example, CURT rates its 13652 Class 3 hitch for the 2026-2027 RAV4 at 4,500 lb and 675 lb tongue weight. Some Class V hitches have a 2 in receiver.

1-1/4 in or 2 in receiver

The receiver size sets which accessories slide in: a 2 in ball mount, bike rack or cargo tray goes in a 2 in receiver. A 1-1/4 in receiver takes 1-1/4 in accessories, or ones listed for both sizes. The Swagman Chinook bike rack is listed for 1-1/4 in and 2 in receivers. A bike rack adds tongue weight: the rack plus the bikes must stay under the tongue weight rating of the hitch and the vehicle.

Cars, compact SUVs and EVs

Many of these vehicles have a choice between a Class I or II hitch with a 1-1/4 in receiver and a Class III hitch with a 2 in receiver. The owner's manual says whether the vehicle is rated to tow, or only to carry a rack. Our vehicle pages group the hitches and wiring that fit each one:

Prices are in Canadian dollars; live prices are on each product page and in the product row below. No duty, brokerage or extra fees at your door.

Toyota RAV4

Toyota RAV4 hitches and wiring

Chevrolet Equinox / GMC Terrain

Chevrolet Equinox / GMC Terrain hitches and wiring: CURT Class II (1-1/4 in) and Class III (2 in) hitches, and wiring harnesses.

Tesla Model 3

Tesla Model 3 hitches and wiring

Tesla Model Y

Tesla Model Y hitches and wiring

Chevrolet Bolt

Chevrolet Bolt hitches and wiring

Hyundai Ioniq 5

Hyundai Ioniq 5 hitches and wiring

Trucks

Weigh Safe says half-ton trucks mostly use a Class III or IV 2 in receiver, and most 3/4-ton and one-ton trucks built after 2008 a Class V 2-1/2 in receiver. Examples we can deliver:

All trailer hitches: choose your vehicle to filter.

The owner's manual tongue weight check

  1. Find your vehicle's towing capacity and maximum tongue weight in the owner's manual, and any equipment it requires.
  2. Read the ratings on the hitch label and on the ball mount.
  3. Weigh or estimate the loaded trailer's tongue weight. GM owner's manuals, for example, ask for 10 to 15% of the loaded trailer weight; other makers give a different range, so follow your manual.
  4. Keep the tongue weight and the trailer weight under the lowest rating: vehicle, hitch, ball mount.

Related guides: Towing Basics: Hitches, Brake Controllers and Wiring, Trailer Hitches for SUVs and EVs: RAV4, CR-V, Tucson, Rogue, Model Y and More, toyota-rav4-hitch-options-canada, hitch-for-chevy-equinox-ev-and-blazer-ev.

Trailer brakes

If your trailer has its own brakes, a brake controller in the towing vehicle runs them, connected through a harness made for that vehicle. Controllers we can deliver: time-delay CURT Venturer Next (51116) and CURT Discovery Next (51126); proportional CURT TriFlex Next (51146); and the Hopkins Impulse (47235), Agility (47294) and Insight Flex-Mount (47297). See all brake controllers.

Hitch class by vehicle

Vehicle (newest generation) Hitch classes we list for it Receivers
Toyota RAV4 2026 3 2 in
Honda CR-V 2023-2026 2, 3 1-1/4 in, 2 in
Hyundai Tucson 2022-2026 3 1-1/4 in, 2 in
Nissan Rogue 2021-2026 2, 3 1-1/4 in, 2 in
Ford Escape 2020-2026 3 2 in
Subaru Crosstrek 2024-2026 3 2 in
Chevrolet Equinox 2025-2026 3 2 in
Toyota Highlander 2020-2026 3 2 in
Ford Explorer 2020-2026 2, 3 1-1/4 in, 2 in
Jeep Grand Cherokee 2011-2021 3 1-1/4 in, 2 in
Hyundai Santa Fe 2024-2026 3 2 in
Kia Sorento 2021-2026 3 2 in
Kia Sportage 2023-2026 3 2 in
Subaru Outback 2026 3 2 in
Tesla Model Y 2020-2026 3 1-1/4 in, 2 in

Where a vehicle name is linked, its guide lists the hitch, the wiring harness and the limit from each part’s fitment record, year by year.

Questions Canadians ask

What are the trailer hitch classes?

Classes I and II have a 1-1/4 in receiver (up to 2,000 and 3,500 lb per Weigh Safe); Classes III and IV a 2 in receiver (up to 8,000 and 10,000 lb); Class V a 2 in, 2-1/2 in or 3 in receiver. Your hitch's rating is the one on its label.

What is the difference between a 1-1/4 in and a 2 in receiver?

The size of the opening: each accessory is made for one size, except ones listed for both, such as the Swagman Chinook.

Does a higher-class hitch raise my towing capacity?

No. Your vehicle's towing capacity and tongue weight limit are in the owner's manual; the lowest of the vehicle's, the hitch's and the ball mount's ratings applies.

Which hitch fits an EV like the Model Y or Ioniq 5?

See our Tesla Model Y and Hyundai Ioniq 5 pages: they list Class III hitches with a 2 in receiver. The owner's manual says whether the EV is rated to tow.

Are prices in Canadian dollars, and do I pay duty at delivery?

Every price on MapleTorque is in Canadian dollars, and shipping is shown before you pay. No duty, brokerage or extra fees at your door.
